Modified Starch Extruder
Certification: CE SGS ISO
Main motor brand: Siemens or Chinese brand
Inverter brand: Delta/Pioneer/Schneider
Capacity: 100-150kg/h
Voltage: three phase 380v 50hz(can be customized)
Material: stainless steel
Screw material: 38CrMoAl/12CrMoV/6542
Extruder type: Twin screw extruder
Description
Product Features
As one of the important raw and auxiliary materials in industry, modified starch can be widely used in paper making, food, textile, construction, medicine and other industries. Manufacturers should actively develop new products and expand the application fields of modified starch.
All our machines are made by stainless steel, which has a longer service life.
The whole production line include mixer - screw conveyor - extruder - air conveyor - dryer - milling machine system.
We have DSE65, DSE70, DSE85... different types of machine.
Product Samples
Production Line Flow Chart
Production Line Video
Technical Parameters
|
Model |
Installed Power |
Power Consumption |
Production Capacity |
Dimension |
|
DSE65 |
72kw |
50kw |
100-150kg/h |
19000*1300*2200mm |
|
DSE70 |
92kw |
65kw |
240-260kg/h |
14000*2000*4000mm |
|
DSE75F |
70kw |
50kw |
200-250kg/h |
32000*1100*1800mm |
|
DSE85W |
108kw |
76kw |
400-500kg/h |
30000*1500*2600mm |
Main Machinery
Model: DSE65
Main motor: 22kw
Feeding: 0.75kw
Rotary cutting: 0.75kw
Heating power: 10kw
Capacity: 100-150kg/h
Size: 19000*1300*2200mm
Screw material: 38CrMoAl
Oil pump motor: 0.37kw
Model: DSE70
Main motor: 37kw
Feeding: 0.75kw
Rotary cutting: 0.75kw
Oil pump: 0.37kw
Heating power: 20kw
Capacity: 200-250kg/h
Screw material: 38cCrmoAl
Model: DSE75F
Main motor: 37kw
Feeding: 0.75kw
Rotary cutting: 1.1kw
Heating power: 16kw
Capacity: 200-250kg/h
Size: 3200*1100*1800mm
Screw material: 38CrMoAl
Oil pump motor: 0.37kw
Our Advantage
- We have more than ten years experience. We are professional manufacturer.
- We have our own factory, which covers an area of nearly 5000 square meters.
- We have three engineers that can provide us professional technical instruction.
- If the problem cannot be solved through the technical instruction manual or installation video, we will arrange engineers to conduct online guidance. If the problem cannot be solved by this way, our engineers can go to your local factory to help you solve the technical problem.
Our Certification
Technical Engineers
FAQ
Q: What if there is a problem with the machine that we can't solve by ourselves?
A: We will guide you online through video, if the problem cannot be solved, our engineers will go to your local factory to provide local service.
Q: Why should I choose your company for the first time?
A: We are professional manufacture with more than ten year experience. We have engineer to provide professional technical instruction. If our machine has poor quality, our company will not exist for so long time.
Q: Do you have any certifications?
A: We have CE, SGS, BV certifications.
Q: What is your payment terms ?
A: 30% T/T in advance, 70% balance before shippment after inspection.
Q: Do you have your own factory?
A: Yes. Our factory covers an area of nearly 5000 square meters.
About Packing & Shipping
• Inside package is plastic film, outside is a wooden or plywood case (based on the customer's need).
• Only plastic film nude packing with wooden pallets.
• Shipping, train, express, or upon clients' demands.
Hot Tags: modified starch extruder, China modified starch extruder manufacturers, factories, Modified Starch Extruder, Starch Manufacturing Plant, Pregelatinized Modified Starch Extrusion Machine, Modified Starch Production Line
