Modified Starch Processing Machine Equipment
Certification: CE SGS ISO
Main motor brand: Siemens or Chinese brand
Electrical components: Schneider, Delta, or Chinese brands
Capacity: 400-500kg/h
Voltage: three phase 380v 50hz(can be customized)
Material: stainless steel
Screw type: Integral screw/combined screw
Extruder type: Twin screw extruder
Barrel type: Square barrel/round barrel
Description
Final Product Pictures
As one of the important industrial raw materials and auxiliary materials, modified starch is widely used in papermaking, food, textile, construction, medicine and other industries. The application of modified starch in food industry is mainly based on functionality, diversity and convenience, focusing on the development of corn starch series products, potato starch, modified starch and derivatives. With the growth of my country's economy and the expansion of the scale of industrial products, the application range of modified starch has been expanding. Continuous development of new products and continuous innovation of new technologies will increase the demand for modified starch. With the gradual reduction of natural petroleum, modified starch produced from renewable resources is a substitute for many petrochemical products, which brings room for development of modified starch. Therefore, the development prospects of modified starch will be very broad.
Production Line Flow Chart Picture
The high-viscosity pregelatinized starch equipment is controlled by the host frequency conversion, and other production lines are controlled by the control cabinet. A production line can be divided into 1-3 control cabinets according to the number of equipment. Concentrated operation, simple and convenient. The required finished product quality is different, and the extruder can be directly adjusted to produce products of various specifications.
Machinery Video
Technical Parameters
|
Model |
Installed Power |
Power Consumption |
Production Capacity |
Dimension |
|
DSE65 |
72kw |
50kw |
100-150kg/h |
19000*1300*2200mm |
|
DSE70 |
92kw |
65kw |
240-260kg/h |
14000*2000*4000mm |
|
DSE75F |
70kw |
50kw |
200-250kg/h |
32000*1100*1800mm |
|
DSE85 |
108kw |
76kw |
400-500kg/h |
30000*1500*2600mm |
Main Machineries on production line
Extruder
Model: DSE65
Main motor: 22kw
Feeding: 0.75kw
Rotary cutting: 0.75kw
Heating power: 10kw
Capacity: 100-150kg/h
Size: 19000*1300*2200mm
Screw material: 38CrMoAl
Oil pump motor: 0.37kw
Air conveyor
Power: 1.1kw/1.5kw/2.2kw
Capacity: 0-2000kg/h
Material: Stainless steel
Dryer
Type: Electric type (we also have oil/gas type and steam type)
Model: kx-3-5, kx-5-5, kx-5-8, kx-7-5, kx-7-8
Capacity: 100kgh to 10tons/h
Material: Stainless steel
Milling machine system
Model: FS-480
Installed power: 15kw
Capacity: 100-300 kg/h
Dimension: 1.3*0.7*2m
Our Engineers
Our services
1. We have professional making formula that can send to customer for reference
2. Our engineer can design production line layout according to factory's sitruation
3. We will test machine before delivery and take videos and pictures for customer
4. We have 24 hours online consultant services. If you have any problems, just feel free to contact us.
About Packing & Shipping
If the customer needs, we can arrange shipping by boat. The reliable freight forwarders we cooperate with will transport the goods to the customer's destination port
