Puffed Snack Processing Line

Puffed Snack Processing Line

Puffed Snack Processing Line is used for making various of puff snacks, with corn and rice as the raw material (the processing of different materials are separately under different moulds). The main machine of this line is DSE Twin Screw extruding machine, the puffs produced from above machine is the semi-finished products. After the final processes of shaping and seasoning, the products become extremely even and crispy. The whole processing is without any frying. We only use a dryer to get ride of the moisture. This production line is a good quality corn puffed extruder snack machine.







① Mixer → ②Screw conveyor → ③ Extruder → ④ Air conveyor → ⑤ Dryer → ⑥ Hoister → ⑦ Flavoring line → ⑧ Cooling conveyor

We can configure the whole production line according to customer's requirements. And our engineer will give production line layout after we confirm the order, so that you can install the whole production line accordingly.

Different model with different capacity. Customers can choose based on their needs. If customers can't decide which capacity they need, our sales man can also recommend machinery according to customer's budget. If you haven't had a budget, you can start from our smallest capacity: 100-150kg/h.

Model	Installed Power	Power Consumption	Output	Size of production line
DSE 65	74 kw	52 kw	100-150 kg/h	17x1.3x2.2(m)
DSE 70	105 kw	75 kw	200-260 kg/h	20x1.5x2.2(m)
DSE 85	205kw	150 kw	350-500kg/h	30x1.5x2.6(m)



1. Our extruder equipped with lubricating oil cooling system. It can prevent the machine from high tempreture, ensuring longer service life

2. Automatic solenoid valve controls the water cooling system. Effectively ensure the stability of the temperature of the barrel, so that the ripening degree of the final product is more uniform, the product effect is better, and the quality is higher.

3. High-strength gearbox, good stability.

4. Automatic temperature control. As long as the heating reaches the set temperature or exceeds the set temperature, the machine will automatically stop heating.

5. Using combined screw, by adjusting the combination mode and angle, it can adapt to more diverse production formulas.



Yongxin Liu (First Class Senior Engineer)

Practical experience: For 20 years, has been committed to the research of leisure food machinery, leading more than 30 projects



Enxin Xu (Second Class Senior Engineer)

Practical experience: Good at the research and production of pet food machinery. Successfully completed multiple 3-6 tons/hour production line construction projects



Sibin Xin (After-sales Group Ⅰ)

Practical experience: 13 years of practical experience, footprints in at least 80 countries, served more than 200 customers around the world, well received by customers.



Guoqiang Fan (After-sales Group Ⅱ)

Practical experience: 18 years of practical experience, have been to at least 30 countries, and provide professional and effective after-sales service to more than 100 customers around the world.



1. Show you and explain you more machines details. Even if you are a start-up, you will learn a lot of professional knowledge.

2. Will give you professional formula if you need.

3. We can help you work together to develop formulations

4. If you plan to visit the factory, we will provide pick-up service

5. We provide a one-year warranty.



You don't need to worry about packaging and transportation issues, we have reliable logistics and transportation, additional insurance to ensure the safe delivery of equipment.
